Product Name:Waste plastic recycling granulator machine HQ-90M

Waste plastic recycling granulator machine

Model: HQ-90M

Youtube Video:https://youtu.be/xnNODb08ZUY


Competitive Advantage (Waste plastic recycling granulator machine):

1. Power saving. Can save 30% power for the similar product in the market.

    It means save 30% electric charge for factory owner.

2. More productive. Screw diameter is more small. It means: there is more material work on our machine than the similar product in the market.

3. Machine with converters, protect whole machine. When there is low electrical current start-up machine, it can project gear box, protect the screw.

4. Machine can work for 800#, 1000# screen mesh.

5. Use more strong material for the charging basket and screw. So more long life for charging basket and screw.


Basic equipment of waste plastic recycling granulator machine:

Single screw Plastic Extruder 1piece

Feeder for granule machine 1piece

Cooling tank with moisture absorption machine   1piece

Plastic pelletizer   1piece

Linear vibrating screen machine  1piece



Product Characteristic (waste plastic recycling granulator machine ):

1. Machine with variable frequency trimming, low power switch on, instantaneous current smooth.

2. Can design and offer multiple heat treatment for screw without extra fee.

3. Gear box with forced cooling filtration system, reach Europe standard.

4. Screw and charging basket use especial steel with heat treatment. Processing reach international standard.

5. Charging basket with P.L.D automatic temperature control, material never change color to yellow ( especially for clear material), will not born blackspot.

6.With automatic or vacuum degassing systems (Option)

7. Can choose Handrotating screen replacement or Hydraulic screen replacement.


Notice: We are one of biggest waste plastic recycling granulator machine manufacture in China.

1. We have more then 200 customer around our factory from 1KM ~30KM, so very welcome to our factory or our customer plastic factory for review our product.

2. Our Single screw pelletizing machine occupy 85% market in local market.

3. One of biggest VCR/VCD manufactory the in world is our customer.


Capability(PC) or(PC+ABS):

Model HQ-60: 80~100KG/HR

Model HQ-90: 200~300KG/HR

Model HQ-120: 350~500KG/HR




Different mode of die head:

Manual type die die head: More steady for the plastic quality, but need man-made working.

Hydraulic type die head: replacement screen is more easy, save labour.


Application:

For material : ABS, PC, PP, PE,HIPS, TPU, PA coloration, mix, modified, added , composite,recycling, make granular. Professional in PC material.



Model No.

HQ-90

              HQ-120

             HQ-150

Output (PC+ABS)

        200~300 Kg/h

            400~600 Kg/h

600~1000

    Install Dimension(M)

12X2X2.7

13X2.5X2.7

16X2.8X2.8

Total Weight

2800 Kg

5100 Kg

                    6200 Kg



1. Main Extruder:

Screw Dia.

Ø90

Ø 120

Ø 150

L/D ratio

33~37:1

33~37:1

33~37:1

Main motor (AC)

 74HP Universal

147HP Universal

214HP Universal

   VF-variable frequency inverter

   VF-variable frequency inverter

   VF-variable frequency inverter

Gearbox

 Gear material : 20CrNiMoA / carburizing quenching

  Gearbox oil cooling system : heat exchanger/ oil filter system

   PID thermo controller

5 Zones

7 Zones



Barrel air cooling

 1/4HP 8 sets

1/4HP 12 sets

1/4HP 14 sets

 (auto-start)

(auto-start)

(auto-start)

Screw material

SACM-645 Nitride treatment, Chrome-plated or SCM-4 bimetallic

Screen changer

 manual or hydraulic

manual or hydraulic

manual or hydraulic

Machine size (mm)

 4500x1800x2300

5240x2400x2390

6500x2800x2500



2. Adjustable Speed Feeding Hopper:

 Reducer motor

0.75KW

1.5KW

2.2KW

                   VF inverter driven

               VF inverter driven

   VF inverter driven

Reducing ratio

60:1

40:1

40:1

Screw dia.

Ø90

Ø90

Ø141

Hopper capacity

500KG/H

800KG/H

1200KG/H

 Machine size(mm)

1000X1000X1280

1200X1200X1280

            1500X1500X1280



3. Water Tank withMoist Sucking & Blowing Motor:

Sucking Motor

1.5KW

2.2KW

2.2KW

  Water tank size(mm)

             4000X360X220

           4500X450X295

                6000X450X295


4.Pellets Cutting Machine:

Motor

 5.5KW

7.5

15

 VF-variable frequency inverter

 VF-variable frequency inverter

 VF-variable frequency inverter

Rotary cutter

  Tungsten steel or

SKD-11,28 blades

  Tungsten steel or

SKD-11,28 blades

  Tungsten steel or

SKD-11,28 blades

Stationary knife

Tungsten steel

       Machine Size (mm)

780X800X1210

780X800X1210

980X980X1228

Machine Weight

500KG

500KG

800KG


5. Vibrating Pelletselector & Storage Tank:

Vibrating motor

0.15KWx 2 sets

Sieving screen

Upper layer Ø 6mm, Bottom 2mm x 20L / 304# stainless steel

Storage tank

Volume : 620 liter / 304# stainless steel

Blower motor

2.2KW

3.8KW

3.8KW

      Machine size (mm)

1400X1300X2700

1400X1300X2700

1500X1400X2800

Machine weight

300KG

300KG

350KG


GuangDong HongQi Plastic Machinery Manufactures is the one of biggest waste plastic recycling granulator machine manufacture in china.

Since Environmental storm swept China, there are more then 500 waste plastic recycling factory move to Southeast Asia country. We export more then 300 waste plastic recycling granulator machine line to them for support their overseas new business.
